PELLETING

• ⦁ Pellet Chamber or front door is made of corrosion/wear resistant, single wall, heavy duty, SS-304 grade stainless steel for longer life. Hinges on Pellet Chamber may be fitted for left or right opening as per requirement.


• ⦁ Fitted with flow eveners or Product Spreader to give better screening effect.


• ⦁ JSPT Pellet Mills are equipped with V-Belt drive for noise less operation. Heavy Flywheel pulley is provided to cope with sudden variation in load. Power from motor is transmitted through direct coupling to counter shaft arrangement.


• ⦁ Proper gap between Die & Rolls is critical to the operation of Pellet Mill. Our pellet mills are equipped with quick, reliable & easy Roller gap adjustment which reduces periodic adjustments.


• ⦁ Feed chute which supplies conditioned mash from Conditioner to Pellet Mill Die is also made of Stainless Steel and fitted with powerful magnets to remove iron particles entering the Pellet Mill Die.


• ⦁ T-shaft is of alloy steel, forged, one piece without welding joints for higher reliability.


• ⦁ All our Pellet Mills are supplied with positive action Shear pin type safety arrangement which stop the Pellet Mill in case of sudden overload.


• ⦁ T-Shaft Housing is of split type design for easy & quick removal of main shaft.
